開放式煉膠機主要用于橡膠的熱煉、壓片、破膠、塑煉和混煉等。
開放式煉膠機主要用于橡膠的熱煉、壓片、破膠、塑煉和混煉等。
| 型號 Type | XK-230 | XK-250 | XK-300 | XK-360 | XK-400 | XK-450 | XK-560 | XK-550B | SK-660 |
輥筒工作直徑 Dia. of working rolls (mm) | 230 | 250 | 300 | 360 | 400 | 450 | 560/510 | 550 | 660 |
輥筒工作長度 Length of working rolls (mm) | 600 | 620 | 750 | 900 | 1000 | 1200 | 1530 | 1500 | 2130 |
前輥線速度 Line speed of front roll (m/min) | 10.21 | 14.1 | 15.1 | 16.25 | 18.65 | 24.26 | 27.72 | 27.94 | 28.6 |
輥筒速比 Speed ratio of rolls | 1:1.19 | 1:1.17 | 1:1.25 | 1:1.25 | 1:1.27 | 1:1.27 | 1:1.2 | 1:1.22 | 1:1.24 |
最大輥距 Max. roller spacing (mm) | 7 | 8 | 10 | 10 | 10 | 15 | 15 | 15 | 15 |
一次加膠量 Capacity of rubber per batch (kg) | 6-10 | 8-15 | 15-20 | 20-25 | 18-35 | 25-50 | 35-50 | 50-60 | 165 |
驅動電機功率 Driving motor power (kw) | 15 | 18.5 | 22 | 30 | 37 | 55 | 90 | 110 | 245 |
外形尺寸 Overall dim. (LxWxH)(mm) | 2800 1200 1120 | 3400 1500 1120 | 3450 1500 1500 | 3780 1850 1750 | 4350 1850 1785 | 5200 2380 1840 | 5480 2284 1978 | 5870 2284 1978 | 7465 3662 2080 |
